ASL 100 Mobile vacuum lifting device

ASL 100

• Application: To be hung in chain or wire hoist in hall or mobile crane
• Safe working load (SWL): 100 kg
• Movement of load: Vertical, 3 fixing possibilities
• Suction cups: 1 × Ø 300 mm
• Vacuum generation: Vacuum pump
• Own weight: 20 kg
• Battery: 12 V / 7,2 Ah
• Battery charger: 230 V
• Glass size: min. 400 × 400 mm, max. recommended up to 2 m²
• Standard colour: White aluminium RAL 9006
